Telemetry Solutions (SignalFire and Pulsar Measurement Range)

$0.00

  • Remotely access measurement data any time you want via your laptop, PC, or mobile device with the power of LTE CAT M1 / NB-IoT connectivity.
  • Automatically store measurement data in the cloud for viewing or reporting and configure alerts for you or your operators in case measurements go outside “normal” levels.
  • Save time and money by being able to view how your measurement systems are operating without needing to be where the devices are installed.
  • Have an infrastructure-independent measurement solution perfect for remote locations. The RANGER is battery-operated and provides power to 2-wire sensors for making measurements. Or, combine the Ranger with a meter that can be powered by 12 VDC and power your measurement solution with a battery and solar combo.

We will be in contact with you within two business days.

Categories: ,
Physical Specifications
Spec: Description:
Operating Temperature: -40 to +185°F (-40 to 85°C)
Input Power: Battery Pack: Four D-cell Lithium Thionyl Chloride, 76AHr
Optional solar power
Optional 10-30Vdc inpu
Battery Life: Up to 8 years
Data Interface: LTE CAT M1 / NB-IoT, auto-selectable
SparkPlug B messaging
Enclosure: Industrial polycarbonate UV Rated; IP64
Electrical Connection: Pluggable terminal block, 16-30AWG screw terminals
Weight: 1 lbs (0.6kg)
Estimated Monthly Data Usage: Check-in interval dependent

1 min = 27 MB
5 min = 5.4 MB
15 min = 1.08 MB
60 min = 0.27 MB
Safety Rating: Class 1 Division 2 Certified, Groups A, B,C, D. Temperature Code T5. Certified to CSA C22.2 No. 213:2017, Conforms to UL 121201:2017, CE Approved
