Pulsar dB Transducer Ultrasonic Level Sensors

$0.00

Non-contacting sensors for level, volume, and flow

  • ATEX Zone 1 & 2 Approval as standard
  • Integral temperature compensation
  • Narrow Beam Angles
  • Standard 2 or 3 core screened cable extensions to 1000 m (3,280.8 ft)
  • DATEM (Digital Adaptive Tracking of Echo Movement) echo processing technology
  • FM/FMc Approval
  • Optional Intrinsic Safety

We will be in contact with you within two business days.

Categories: ,
General Specifications
Spec: Description:
Sensor body material Valox 357 U and syntactic foam face
Maximum separation 500 m (1,640.4 ft)
Mounting connection BSP or 1 in NPT
Enclosure protection IP68/NEMA 6P
Operating Temperature Standard: -40 °C to +90 °C (-40 °F to +194 °F)
Hazardous Area: -40 °C to +75 °C (-40 °F to +167 °F)
CE Approval 2014/30/EU – EMC & 2014/34/EU ATEX Directives. Standards applied: EN 60079-0:2012+A11:2013/ EN 60079-11:2012 / EN 60079-18:2009 / EN 60079-26:2007 / EN 61326-1:2013
ATEX Approval Standard ATEX EEx m II T6 or optional EEx ia IIC T6. FM/FMc approval. (dB50 not approved)
Intrinsic Safety Optional
Accuracy 0.25% or 6 mm (0.2 in) whichever is greater
Resolution 0.01% or 2 mm (0.1 in) whichever is greater
