NTL-ExT6

$0.00

• Compact design

• Set temperature

• High switching capacity


We will be in contact with you within two business days.

Category:
NTL-ExT6
Switch temperature difference 4K (±1K tolerance)
Sensor element thermostatic bimeta
Contact type (1-pole) opens with rising temperature
Service life > 100 000 cycles
Max. switching capacity 250VAC, 1.3 (0.65) A
Max. inrush current AC 4A for 12 sec.
Connection Si HF – JZ 3×0.5mm², length 1m
Mounting mounting bracket with nut M8 (see illustration)
Casing aluminium, black anodised
Dimensions length 110mm
Weight approx. 0.2kg
Fitting position variable
Storage temperature -45 to +70°C (-49 to +158°F)
Operating/Storage humidity max. 90% RH (non-condensing)
Protection type/Protection class IP65 / I (earthed)
Art. No Ambient temperature¹ Switch-off temperature Ex protection type II 2 GD
ExT6.0 0 to +60°C +15°C (±4K tolerance) Gases: Ex d IIC T6 Gb Dusts: Ex tb IIIC T85°C Db IP6X
ExT6.1 +32 to 140°F +25°C (±4K tolerance) Gases: Ex d IIC T6 Gb Dusts: Ex tb IIIC T85°C Db IP6X

¹ Ambient temperature inside of the cabinet/enclosure
