Technical Data
| NT 71-F |
| Switch temperature difference |
+/-5℃ |
| sensor element |
thermostatic bimetal |
| Contact type |
snap-action contact |
| service life |
>100,000 cycles |
| Max.switching caoacity |
250VAC,10(2)A |
| Max.inrush current |
AC 16A for 10 sec |
| Connection |
4-pole terminal,clamping torque 0.5Nm max.:rigid wire 2.5mm2(AWG 14)
stranded wire1 1.5mm2(AWG 16) |
| Mounting |
clip for 35mm DIN rail,EN 60715 |
| Casing |
plastic according to UL94 V-0, light grey |
| Dimensions |
67x50x46mm |
| Weight |
approx.90g |
| Fitting Position |
variable |
| Operating/Stirage temperature |
-45 to +80℃(-49 to +176℉) |
| Operating/Stirage humidity |
max.90% RH (non-condensing) |
| Protection type |
IP20 |
When connecting with wires, wire end ferrules must be used.
Important note: The contact system of the regulator is subjected to environmental influences, thus the contact
resistance may change. This can lead to a voltage drop and/or self-heating of the contacts.
| Art.No. |
Setting range |
Signal current |
| 860041 |
Contact breaker(NC) |
0 to +60℃ |
Contact maker(NC) |
0 to +60℃ |
| 860042 |
Contact breaker(NC) |
+32 to 140℉ |
Contact maker(NC) |
+32 to 140℉ |
| 860043 |
Contact breaker(NC) |
-10 to +50℃ |
Contact maker(NC) |
+20 to +80℃ |
| 860044 |
Contact breaker(NC) |
+14 to +122℉ |
Contact maker(NC) |
+68 to +176℉ |
| 860045 |
Contact maker(NC) |
0 to +60℃ |
Contact maker(NC) |
0 to +60℃ |
| 860046 |
Contact maker(NC) |
+32 to 140℉ |
Contact maker(NC) |
+32 to 140℉ |
