IMP Lite Low-cost (Simple Level Measurement)

$0.00

  • Compact, self-contained level measurement
  • 2-wire configuration
  • RJ11 port
  • Up to 10 m (32.8 ft) range available

We will be in contact with you within two business days.

Category:
General Specifications
Spec: Description:
Dimensions 175 mm (6.9 in) H x 130 mm (5.1 in) D
Cable entry 2 x 16 mm (0.6 in) cable glands, 3.5 mm to 10 mm (0.1 in to 0.4 in) cable diameter
Mounting IMP3 – 3 m (9.8 ft) version: 1.5 in BSP/NPT
IMP 6 – 6 m (19.7 ft) version: 1.5 in BSP/NPT
IMP10 – 10 m (32.8 ft) version: 2 in BSP/NPT
Suits BSP & NPT, parallel and tapered
Weight Approximately 1 kg (2.2 lbs)
Temperature (Process) -40 °C to 80 °C (-40 °F to 176 °F)
Temperature (Ambient) -20 °C to 65 °C (-4 °F to 149 °F)
Input Voltage 11-30 V, 3.5-22 mA
Accuracy ±0.25% or 6 mm (0.2 in); whichever is greater
Resolution ±0.1% or 2 mm (0.1 in); whichever is greater
