Vertical Eye Washer

Vertical eye washer
Product features:
Material:SS304
Vertical eye washer
Function: Eye and face rinse
Nominal pressure: 1.0 Mpa
Work pressure: 0.2-0.4 Mpa
Test pressure: 2.0 Mpa
Use ambient temperature: 0-40°C eye/Face
Washing Water Flow:>11.4L/MIN Eyewash
flow: >1.5L/MIN
Equipped with dual flow control valve
(optional device)
Influent height: 850mm
Drainage height: 101mm
Inlet size: 1/2 inch internal thread
Drainage outlet size: 1 -1/4 inch internal
thread Production Standard:
ANSIZ358.1-2014

Note: The size of the intake can be customized according to the user’s needs. It is suggested that emergency valves and filters be installed and maintained at the intake.
