PDFM 5.1 Portable Ultrasonic Non-invasive Pipe Flow Measurement

$0.00

  • Clamp-on Ultrasonic Transducer
  • Handheld Meter with large backlit LCD Display and Totalizer
  • Internal Battery and/or AC Powered
  • Built-in 5-Key Calibrator
  • 300,000 point Data Logger
  • USB Output and Windows software
  • 4-20 mA Output
  • Rugged, watertight Carry Case

We will be in contact with you within two business days.

Category:
General Specifications
Spec name: Description:
Flow Rate Range ±0.046 m/s to 12.2 m/s (±0.125 ft/s to 40 ft/s) in most applications
Flow Rate Range Ultrasonic Sensor mounts on any pipe from 12.5 mm to 4.5 m (0.5 in to 180 in) ID
Display White, backlit matrix – displays flow rate, totalizer, operating mode, and calibration menu
Power Input Built-in NiMH battery for up to 18 hours continuous operation External charger with 100-240 V AC 50/60 Hz input
Outputs 4-20 mA (500 ohms) when AC powered USB for Data Log transfer by direct PC connection
Data Logger Programmable 300,000 data point capacity, time and date stamped or formatted flow reports including total, average, minimum, maximum, and times of occurrence
PC Software ‘Greyline Logger’ for Windows Vista or higher. Retrieves, displays, and saves data log files
Operating Temperature (Electronics) -23 °C to 60 °C (-10 °F to 140 °F)
Electronics Enclosure Portable, ABS enclosure
Carry Case Rated IP67 with protective molded foam insert
Accuracy ±2% of reading or 0.03 m/s (0.1 ft/s). Requires solids or bubbles minimum size of 100 microns, minimum concentration 75 ppm. Repeatability: ±0.1%, Linearity ±0.5%
Calibration Built-in 5-key programming with a user-friendly calibration menu. Password protected.
Language Selection English, French, Spanish
Sensitivity Adjustable cut-off, Damping: adjustable



Sensor Specifications
Spec name: Description:
Standard Model PSE4 Clamp-on, single-head ultrasonic for pipes from 12.5 mm to 4.5 m (0.5 in to 180 in) ID with 3.4 m (12 ft) shielded dual-coaxial cable
Sensor Mounting Kit Stainless steel pipe clamp and 150 g (5.3 oz) silicone coupling compound
Operating Temperature -40 °C to 150 °C (-40 °F to 300 °F)
