NTL-LD120

$0.00

Technical Parameters

Model Power
Supply		 Fan Size
(mm)		 Air Flow Rate
(free blow)
(m3
/h)		 Air Flow Rate
(with Mat)
(m3
/h)		 Power
Consumption
(W)		 Current
Consumption
(A)		 Noise
Level
(dBA)
LD120 – without fan – – – – –
LDF120-230A-C 230VAC 80×80×25 30/41 24 14/12 0.07 27/30
LDF120-230B-C 230VAC 80×80×38 39/48 24 13/10 0.078/0.062 27/30
LDF120-230V-C 230VAC 80×80×38 66/78 26 14/11 0.09/0.07 27/30
LDF120-115A-C 115VAC 80×80×25 30/41 24 14/12 0.07 27/30
LDF120-115B-C 115VAC 80×80×38 39/48 24 13/10 0.078/0.062 27/30
LDF120-115C-C 115VAC 80×80×38 66/78 26 14/11 0.09/0.07 27/30
LDF120-D-C 120&230VAC 80×80×38 39/48 26 13/10 0.078/0.062 27/30
LDF120-12-C 12VDC 80×80×38 84 30 4.8 0.4 30
LDF120-24-C 24VDC 80×80×38 84 30 4.8 0.2 30
LDF120-48-C 48VDC 80×80×38 84 30 4.8 0.1 30

Normally is airflow direction”Out”, if you need airflow direction “In”, when place order, please advice.


We will be in contact with you within two business days.

Category:

Technical Data

NTL-LDF120
Axial fan, ball bearing service life L10 at +40°C (+104°F): min. 50,000h fan body aluminium, rotor metal
Connection 2 stranded wires, 300mm
Enclosure cut-out 93 x 93mm+1 mm
Mounting frame 4 built-in ratchet braces for mounting (6 notches for wall thickness 1-4mm).
Additional use of screws possible if needed.
Filter mat G4 acc. to DIN EN 779, filtering degree 94%
Filter material New ABS material confirm to RoHS, Fireproof or not fireproof can be choose
Operating/Storage temperature -25 to +65°C (-13 to +149°F)/-40 to +70°C (-40 to +158°F)
Operating/Storage humidity max. 90% RH (non-condensing)
Protection type/Protection class IP54 / I (earthed)
