Semiconductor Heater NTL 151

• Pressure clamp connectors

• Dynamic heating up

• Wide voltage range

• Energy saving

• Clip fixing, Quick installation

These heaters are used in enclosures where damage from condensation must be prevented, or where the temperature may not fall below a minimum value. The aluminium profile heater body design has a chimney effect and distributes the heat evenly. The heaters are designed for permanent operation. Pressure clamb connectors save time and simplify installation.


We will be in contact with you within two business days.

Category:

Technical Data

NTL 151
Operating voltage 120-260V AC/DC or 12V DC or 24V DC or 48V DC¹ (min. 110 V, max. 265 V)
Heating element PTC resistor – temperature limiting
Heater body extruded aluminium profile, anodised
Connection 3 pressure clamps for stranded wire 0.5-1.5mm² (with wire end ferrule) and

rigid wire 0.5- 2.5mm²
Connection casing plastic according to UL94 V-0, black
Mounting clip for 35mm DIN rail, EN 60715
Fitting position vertical airflow(air outlet up,connection on botton)
Operating/Storage temperature -45 to +70℃(-49 to +158℉)
Operating/Storage humidity max.90%RH(non-condensing)
Protection type/Protection class IP20/I(earthed)
Accessoires screw fixing,
Note other voltages on request

Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.

Art.No. Heating capacity² Length(L) Weight(approx)
860063 15W 65mm 0.25kg
860064 30W 65mm 0.25kg
860065 45W 65mm 0.25kg
860066 50W 80mm 0.35kg
860067 60W 140mm 0.35kg
860068 75W 140mm 0.45kg
860069 100W 140mm 0.45kg
860070 150W 220mm 0.65kg
