Flow Monitor Non-Invasive Flow Measurement sensor

$0.00

Fixed Installation for Pipe Flow Monitoring

  • Provides power for FlowPulse 22-28 V DC and Universal AC 85-264 V
  • Display for flow / velocity from a single FlowPulse controller
  • Setup of FlowPulse sensor
  • Two programmable relays for control and alarm
  • Daily system / resettable totalizers
  • Logging, set up, and download via optional Log Software

We will be in contact with you within two business days.

Categories: ,
General Specifications
Spec: Description:
Controller Body Dimensions: 130 mm x 150 mm x 63.5 mm (5.12 in x 5.9 in x 2.5 in)
Weight: 0.65 kg (1.42 lbs)
Enclosure Material: ABS base with polycarbonate lid, flammability rating UL94HB
Maximum Separation: 500 m (1,640 ft)
Max and Min Temperature (Electronics): -20 °C to +50 °C (-4 °F to +122 °F)
Operating Voltage: 85-264 V AC 50/60 Hz, 22-28 V DC
Power Consumption: 10 W maximum power (typically 8 W)
