ABS Compound Eye Washer

Product features:
Material: Environmental ABS Material
Use environment: Suitable for strong acid
and alkali indoor environment
Flushing sprinkler: diversion technology,
flushing range expanded by 20%
Function: Spray +Eyewash
Nominal pressure: 1.0 Mpa
Work pressure: 0.2-0.4 Mpa
Test pressure: 2.0 Mpa
Use ambient temperature: 0-40°C
Spray water flow:>75.7L/MIN
eye/Face Washing Water
Flow:>11.4L/MIN
Eyewash flow: >1.5L/MIN
Eye wash height: 1020 mm
Rinse height: 2180 mm
Inlet size: 1-1/4 inch internal thread
Drainage outlet size: 1 -1/4 inch internal
thread
Production Standard: ANSIZ358.1-2014
Note: The size of the intake can be customized according to the user’s needs. It is suggested that emergency valves and filters be installed and maintained at the intake.
